3 Channel First Person View Video Switcher

3 way RC video switch allows switching between 3 cameras while flying FPV. You can switch between flight camera, back view camera and camera facing down or use switch to see view from camera that takes pictures.

Features:

• 3 video inputs, 1 video output
• Regular PWM servo channel input
• Video input and output power pins interconnected
• Operating voltage 4V ~ 7V

Connecting:

Simply connect the 3-way video switch to RC receivers regular servo channel.

Video connectors:

The 3-way video switch has 3 video inputs and 1 video output. Connection is made with common 3 pin servo style connectors.
All pin headers have same pin functions: GND, +V, Video

Ground pin is always located at left if facing connectors and holding board with components on top. GND pins are marked with line on board.

Video power:

All middle pins of 3 pin video connectors are interconnected to share same power between video cameras and video transmitter connected. You can power all devices either by feeding voltage to one of video devices connected or by soldering additional leads to battery input and connect battery.
