Sony Super HAD II CCD 600TVL First Person View CCD Camera

Sony 600TVL FPV Camera

Introducing the super high resolution Sony 600TVL FPV camera. This camera is highly regarded in the FPV scene as one of the best cameras money can buy.

The camera features an external board controller, this can be connected to adjust settings in the menu to get the camera fine-tuned to your personal taste (although we usually just fly with the default settings as we find these work really well in most light conditions!)

The camera is shipped with a 2.8mm lens as standard, this gives the pilot an excellent field of view, whilst giving a sharp image and keeping everything in focus.

Features:

• Colour 600TVL Black & White 650TVL High Picture Quality
• 1/3'' SONY SUPER HAD II CCD
• High grade OSD menu
• D-WDR
• DNR (Digital Noise Reduction)
• Low Power Consumption
• Back light compensation (BLC)
• Motion detective function
• MIRROR
• Anti-exposure function (support car license recording)
• 8 private areas Shading function
• Low illumination:0.01Lux
• BNC output
• White dot repair

Specifications:

• Image Sensor - 1/3 SONY SUPER HAD II CCD
• Horizontal Resolution - 600TVL
• Dimensions - 38mmX38mm
• Power - 12V DC (±10%)
• Weight  14g
•  -0.01Lux/1.2F
• Effective Pixel - PAL:753(H)*582(V),NTSC:768(H)*494(V)
• Signal System - PAL/NTSC
• Auto White Balance - Manual/Auto/Auto tracking
• S/N Ratio - >60dB(AGC OFF)
• Electronic Shutter Speed - PAL:1/50-1/100,000sec;NTSC:1/60-1/100,000
• Auto Gain Control - Off/Low/Mid/High optional
• Back light compensation (BLC) - Off /BLC/ Anti-exposure
• Motion Detection (MD) - On/Off (multi-level sensitivity)
• Video Output - 1.0Vp-p 75 ohm BNC output
• Edge light compensation - Yes
• IR image optimize - Anti exposure of the object in the middle
• DNR - 2DNR
• Day/Night Switch - Auto/Color/B&W/Outside control (position start and end controllable)
• White dot repair - Yes
• Image adjust - Yes
• Function Control - OSD
• Operation Temp. - 10 C~50 C

Shipping Contents:

• 1x Sony 600TVL FPV Camera inc 2.8mm Lens
• 1x Control Board & Hook-up Cable
• 1x Default AV/Power Cable
• 1x Lightweight AV/Power Cable
